The ability of granting or denying access based on talking to and seeing your visitors as if in person, gives one a true sense of security and great peace of mind. Especially for a business, it eliminates the need for personnel to be physically stationed at the door/gate, which improves productivity and frees them up to work on other things.
-
-
Physical Features
-
-
Body material: aluminum panel
-
Display: IPS LCD
-
Screen: 7” capacitive touch screen
-
Camera: 3M pixels with IR Sensor automatic lighting
-
Power consumption: 12V DC input, <12W
-
G-sensor for tamper alarm
-
Enclosure rating: IP65
-
Collision-proof rating: IK06
-
Installation: flush mounting or wall-mounting
-
Dimensions: 324x130x27 mm
-
-
-
Entry Features
-
RF card reader: 13.56MHz & 125kHz
-
Digital keypad: Pass Number
-
Facial recognition: 32 points of recognition
-
Other biometric method: gesture
Interface Features
-
1xRJ45 10/100M Mbps Ethernet port
-
Output relay: 2 relays for door opener
-
Relays controlled individually by DTMF tones
-
RS485 port
SIP Features
-
Line: 2 SIP accounts
Audio Features
-
1 built-in microphone with IP67 rating
-
2W speaker with IP66 rating
-
Speech quality: 7 kHz
-
Echo cancellation
-
Voice activity detection
-
Comfort noise generator
-
Max. call length setting
Video Features
-
Viewing angle: 72º
-
Resolution: up to 720p
-
Image transfer rate: 720p@30fps max.
-
Camera permanently operational
-
Auto-night mode with LED illumination
-
Illumination: 0.1LUX min.
-
Auto white balance
-
Internal light sensor: image lighting during dark hours
-
Codec: H.263 and H.264
-
Support RTSP
-
Compliance with ONVIF
Network Features
-
NTP for auto time setting
Administration Features
-
Auto-provisioning: FTP/TFTP/HTTP/HTTPS/PnP
-
Configuration management: web- or touch screen-based management or auto provisioning
Application Scenarios
-
Control remote site entry over the internet
-
Perfect for apartment / flat intercom with door access control
-
Bonus function: business information display or a welcome screen
